Ekko EB12E-138 Full Powered Straddle Stacker 138" Height 2640 lbs. New

WISHLIST
$97.39
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    The EKKO EB12E-138 Electric Straddle Stacker is designed with the combination of the versatility of a forklift, reach truck and a walkie stacker.



    It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing.


    Overview (Right Column)
    Brand new and manufacturer direct
    3 year limited manufacturer's warranty
    Ships from manufacturer in CA
    Fast processing with free shipping
    Authorized Ekko dealer



     Outlets
    Features (Left Column)
    • Load Capacity 2640 lb
    • Raised Height 138" (11.5 ft)
    • Adjustable Forks 8.3 - 33.5"
    • Adjustable Legs 45.7 - 59.1"
    • Fork Length 45.3"
    • Curtis Controller
    • 24V Drive Motor
    • 24V Lift Motor
    Features (Right Column)
    • Internal Charger
    • Battery 2 x 12V/100Ah Included
    • Polyurethane Wheels
    • Ergonomic Handle and Controls
    • Steel Construction
    • Robotic Welding
    • Charger Included
    • 3 Years Limited Warranty
    Product Specifications (Left Column)
    • Model: EB12E-138
    • Load capacity (lb): 2640
    • The max. lifting height (in): 138”
    • Load center distance (in): 24
    • Fork length (in): 45.3
    • Single fork width (in): 4
    • Overall fork width (in): 8.3 - 33.5
    • Lowered fork height (in): 2.35
    • Fixed leg length (in): 36.5
    • Adjustable legs (in): 45.5 - 59.1
    • Turning radius (in): 52.6
    • Overall length (in): 70
    • Max Overall width (in): 61
    Product Specifications (Right Column)
    • Extended mast height (in): 154
    • Lowered mast height (in): 92
    • Battery voltage (dimensions) (in): 2 × 12V/100AH（10/6.6/8.5）
    • Internal Charger (V/A): 24V/15A
    • Lifting Motor (V/W): 2.2kw. Lift speed, laden/unladen: 92/136mm/s Lowering speed, laden/unladen: 112/98mm/s
    • Driving Motor (W): 0.75kw. Driving speed: laden/unladen: 4.0/4.2km/h
    • Service Weight (lb): 1450




    Package Contents:

    • Full Powered Straddle Stacker
    • EB12E-138 Series Brochure
    WARRANTY

    This item comes with a 3 year limited manufacturer's warranty, please see below.
